Diamond Products 30″ Propane CORE CUT 35HP Walk-Behind Concrete Saw CC3535JBVP-30

Diamond Products

30″ Propane CORE CUT 35HP Walk-Behind Concrete Saw CC3535JBVP-30

The CC3535JBVP-30 features a 35 HP Briggs Vanguard engine converted to propane vapor draw and is a great mid-size saw for service, utility work, and rental. The jackshaft allows full engine power and 30% more torque. This model boasts the strongest frame on the market and an engine adjustment mechanism for belt tightening and maintenance. Weighing 1,095 pounds, this saw also features self-propelled drive for easy cutting and still fits through a 30″ door frame. This saw is compatible with a 30″ blade.

FEATURES:

• Briggs Vanguard engine converted to propane vapor draw
• Great mid-size saw for service, utility work, and rental
• Jackshaft allows full engine power
• Easy to maneuver self-propelled drive
• Engine adjustment mechanism for belt tightening and maintenance
• Strongest frame on the market
• 30% more torque with jackshaft design
• Fits through a 30″ door frame


SPECIFICATIONS:

Max Depth of Cut:	12-3/8″
Blade Shaft Diameter:	1-3/4″
Arbor Size:	1″ with Single Drive Pin
Blade Shaft Drive:	6 Belts
Blade Mounting:	Right or Left
Blade Raise/Lower:	Electro-hydraulic Pump
Transmission:	Eaton Model 10
Drive Speed:	0-200 Feet per Mintue
Air Filter:	4-Stage
Fuel Tank Size:	33.5 lbs



INCLUDES:
Hour Meter
Frame Lift
Cutting Depth Indicator
Quick Disconnect Blade Flanges
Telescoping Front Pointer
